Cisco C9404R-48U-BNDL-E Switch

Cisco C9404R-48U-BNDL-E Switch

[shortdesc]
  • Managed, Rack-mountable, 2 x line-card slots, 2 x Supervisor slots, Integrated PoE (2880W per slot), Layer 3, Network Essentials License
[/shortdesc]
[properties]
Properties Cisco C9404R-48U-BNDL-E Modular Chassis Bundle
Description Enterprise modular switch with UPOE ports and Network Essentials license
Product Type Modular Switch Chassis Bundle
Compatibility Cisco Catalyst 9400 Series Line Cards, Supervisors, and Power Supplies
Mount Type Rack-mountable (6RU)
[/properties] [specifications]
Supervisor Engine C9400X-SUP-2XL (Redundant Supported)
Line Card Included C9400-LC-48U (48 x UPOE Ports)
Max Bandwidth per Slot 480 Gbps
Max PoE Budget 4320W per slot
Power Supply Bays 4
Dimensions (H x W x D) 10.47 x 17.30 x 16.30 in
Weight (with fan) 39.0 lb (17.2 kg)
Operating Temperature -5°C to +45°C (up to 1800m)
[/specifications] [accesories]
Included Items Chassis, 48U line card, supervisor engine, fan tray, rack mount kit
Included Kits C9404-ACC-KIT, C9404-RACK-19-KIT, power blank panels
Optional Accessories Additional line cards, second supervisor, redundant power supplies
[/accesories]

Cisco Catalyst C9404R-48U-BNDL-E Switch

The Cisco Catalyst C9404R-48U-BNDL-E Switch is designed for high-density, scalable enterprise access networks, offering 48 Universal Power over Ethernet (UPOE) ports to power and connect a wide range of PoE-enabled devices, including wireless access points, IP phones, and cameras. This modular switch supports Cisco’s Network Essentials license, providing essential Layer 3 routing, security, and automation capabilities to ensure efficient and secure network operations in large campus and branch deployments.

Key Features:

  • 48 x UPOE Ports: Provides up to 90W of power per port, ideal for powering PoE-enabled devices such as IP phones and wireless access points.
  • Cisco StackWise Virtual Technology: Simplifies management and enhances redundancy across multiple switches.
  • Layer 3 Routing: Supports protocols like OSPF, EIGRP, and BGP for dynamic routing and traffic segmentation.
  • Energy-Efficient Design: Compliant with IEEE 802.3az standards, optimizing energy consumption without sacrificing performance.
  • Network Essentials License: Unlocks essential routing, automation, and security features for reliable network management.

Technical Overview:

  • Recommended for: Enterprise access networks, large campuses, and branch offices.
  • Ports: 48 x 10/100/1000 UPOE ports.
  • Switching Capacity: 240 Gbps.
  • Forwarding Rate: 120 Mpps.
  • Layer 3 Features: OSPF, EIGRP, BGP, MPLS, and VRF-Lite.
  • Management: Managed via Web UI, CLI, SNMP, and Cisco DNA Center.
  • Licensing: Network Essentials.
  • Energy Efficiency: Supports IEEE 802.3az standards for energy-efficient operation.

You can check the related tab for the Cisco C9404R-48U-BNDL-E datasheet.

$10,708.00
Cisco C9404R-48U-BNDL-E Switch—
$10,708.00
